Weighing kiosk VIGILE ABS-IDe-400-PC

VIGILE ABS IDe-400-PC weighing kiosk for vehicles

The weighing kiosk VIGILE ABS-IDe-400-PC has been conceived for automatic weighing on weighbridges (or truck scales), for measuring the weight of trucks, semi-trailers and construction equipment.

Its approved weighing indicator guarantees the accuracy of the weight measurement.

Vehicle drivers are guided step-by-step through messages and can enter numeric or alphanumeric data.

The weighing process initiated by the reading of a badge ends with the edition of a weighing ticket (weighing receipt).

Its integrated weighing indicator is approved by LNE.



Several badge technologies:

  • RFID1 ( Wiegand)
  • RFID2 ( Mifare)
  • Barcode
  • QR Code



The weighing kiosk VIGILE ABS IDe-400-PC exists in 2 types of configurations :

  • VIGILE kiosk software in connection with a computer
  • Autonomous weighing kiosk software

This kiosk has two types of finishes :

  • Reinforced ABS/PPM case
  • Stainless steel case



Mounting accessories for this kiosk:

  • Galvanized round column diameter 90 mm :
    • Light vehicles heights
    • Trucks height
  • Wall mounting (set of 2 mounting plates for ABS version only)



Communication ports :

  •  COM1: RS232 link for controlling the ticket printer and the badge reader.
  • COM2 (options) of your choice :
    •  RS232
    •  RS485
    • Current loop
    • Ethernet (xPort)
  • BUS MASTER CAN (kiosk link, digital loadcells, weight repeaters)
  • One M1 input for 6-wire analog loadcells



Options of the weighing kiosk VIGILE ABS-IDe-400-PC:

  • Isolated 4I/4O card (option 0/10 V or 4/20 mA)

Configuration of the 4 inputs (AUTONOMOUS kiosk software) :

  • E1 / E2 / E3 / E4 : disused

Configuration of the 4 outputs (AUTONOMOUS kiosk software) :

  • S1 : Low threshold
  • S2 : Finished entrance weighing / request to evacuate the weighbridge or scale
  • S3 : Finished exit weighing/request to evacuate the weighbridge or scale
  • S4 : Weighing type “Gross / Tare / Net” completed / request to evacuate the weighbridge or scale

A USB key reader allows you to export weighing data for use in a spreadsheet program (e.g. Excel).

This USB key reader is accessible through a waterproof plug under the terminal.



Product reference

: 00001472+00001475
